Brand: HPE · SKU: D3940 · MPN: D3940 · Category: Components
The HPE Synergy D3940 Storage Module is a direct attached storage module designed for use in HPE 12000 Synergy frames, featuring 40 Small Form Factor (SFF) drive bays. It provides composable storage for up to 10 compute modules in a single frame via the HPE Synergy 12Gb SAS Connection Module. Synergy storage is optimized for software-defined storage solutions like HPE StoreVirtual VSA, VMware VSAN, Microsoft Storage Spaces, and Hadoop. It supports a mix of 12G SAS or 6G SATA HDDs and SSDs in Smart Carriers, though logical grouping must be across identical drive types. It offers a non-blocking 12 Gb SAS fabric end-to-end, enabling high bandwidth and performance, especially for solid-state drives. The module occupies two half-height bays in the frame, and up to five can be used in one frame for a potential density of up to 200 SFF drives. Redundancy can be achieved by adding a second I/O adapter and connection module.
| Interface | HPE Synergy 12Gb SAS Connection Module |
|---|---|
| SAS Speed | 12 Gb/s |
| Drive Bays | 40 x hot-swap - 2.5" SFF |
| SATA Speed | 6 Gb/s |
| Device Type | Storage drive cage / Storage Blade |
| Supported Drives | SAS, SATA HDD and SSD (in Smart Carriers, excluding NVMe or dual-Flash) |
| Power Consumption | 500 Watts, Maximum |
| Controller Options | HPE Smart Array P542D (example) |
| Frame Compatibility | HPE Synergy 12000 Frame |
| Storage Architecture | Direct Attached Storage (DAS) |
| Maximum Modules per Frame | 5 |
| Drive Form Factor Compatibility | 2.5" |
| Warranty | 3-year Limited warranty - parts and labour - on-site (Standard Support/Care Pack options available) |
| Weight | 9.39 kg (Unloaded/w/o drives) |
| Dimensions | 60.96 cm x 12.7 cm x 21.59 cm (24 in. x 5 in. x 8.5 in.) (DxWxH) |
The HPE Synergy D3940 Storage Module provides 40 SFF drive bays for direct attached, composable storage within the HPE Synergy 12000 Frame. It is optimized for software-defined storage and high-performance workloads due to its 12 Gb SAS connectivity, supporting both HDD and SSD drives.
