A9K-4HG-FLEX-TR, Cisco ASR 9000 Router, 4x100GE/400G, Flexible Interface, No Fan & PSU

SKU: CIS:A9K-4HG-FLEX-TR · MPN: CIS:A9K-4HG-FLEX-TR · Category: Components

A9K-4HG-FLEX-TR, Cisco ASR 9000 Router, 4x100GE/400G, Flexible Interface, No Fan & PSU
Request for Quote
In Stock • 10 units

ASR 9000

View Components Products

Specifications

SafetyCisco ASR 9000 Series Routers are designed to meet: ● UL/CSA/IEC/EN 60950-1 ● IEC/EN 60825 Laser Safety ● ACA TS001 ● AS/NZS 60950 ● FDA: Code of Federal Regulations Laser Safety
OptionsEach line card is available as either a service-edge-optimized or packet-transport-optimized line card
Ethernet● 100-Gbps IEEE 802.3ba compliant ● 100 Gigabit Ethernet PHY monitoring ● 400-Gbos IEEE 802.3bs compliant ● IEEE 802.x flow control ● Full-duplex operation ● Per-port byte and packet counters for policy drops; oversubscription drops; Cyclic Redundancy Check (CRC) error drops; packet sizes; and unicast, multicast, and broadcast packets
ImmunityCisco ASR 9000 Series Routers are designed to meet: ● IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air) ● IEC/EN-61000-4-3: Radiated Immunity (10V/m) ● IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal) ● IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM) ● IEC/EN-61000-4-5: Signal Ports (1kV) ● IEC/EN-61000-4-5: Surge DC Port (1kV) ● IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms) ● IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m) ● IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage Variations ● KN35
Performance● 100-Gbps line-rate throughput per QSFP28 port ● 400-Gbps line-rate throughput per QSFP-DD port
Port density2 Terabit Line Card: 15 QSFP28 ports capable of 10Gb, 40Gb, and 100Gb Ethernet traffic support. 5 QSFP-DD ports capable of 10Gb, 40Gb, 100Gb, 200Gb, and 400Gb Ethernet traffic support. 0.8 Terabit Line Card: 6 QSFP28 ports capable of 10Gb, 40Gb, and 100Gb Ethernet traffic support. 2 QSFP-DD ports capable of 10Gb, 40Gb, 100Gb, 200Gb, and 400Gb Ethernet traffic support.
EMC standardsCisco ASR 9000 Series Routers are designed to meet: ● FCC Class A ● ICES 003 Class A ● AS/NZS CISPR 32 Class A ● CISPR 22/CISPR 32 Class A ● EN55022/EN55032 Class A ● CCI Class A ● CNS-13438 Class A ● KN32 Class A ● IEC/EN 61000-3-2: Power Line Harmonics ● IEC/EN 61000-3-3: Voltage Fluctuations and Flicker ● EN50121-4 Railway applications Part 4: Emission and immunity of the signaling and telecommunications apparatus ● EN50121-3-2 Railway applications Part 3-2: Rolling stock - Apparatus
ETSI/EN standardsCisco ASR 9000 Series Routers are designed to meet: ● EN300 386: Telecommunications Network Equipment (EMC) ● ETSI 300 019 Storage Class 1.1 ● ETSI 300 019 Transportation Class 2.3 ● ETSI 300 019 Stationary Use Class 3.1 ● EN55022: Information Technology Equipment (Emissions) ● EN55032: Multimedia Equipment (Emissions) ● EN55024: Information Technology Equipment (Immunity) ● EN55035: Multimedia Equipment (Immunity) ● EN50082-1/EN-61000-6-1: Generic Immunity Standard
Operating altitude–60 to 4000 m (up to 2000 m conforms to IEC, EN, UL, and CSA 60950 requirements)
Storage temperature–40 to 158°F (–40 to 70°C)
Chassis compatibilityCompatible with the Cisco ASR 9006, ASR 9010, ASR 9904, ASR 9906, ASR 9910, ASR 9912, and ASR 9922 chassis
Operating temperature41 to 104°F (5 to 40°C) Note: Limitations may apply when using high-power optics
Storage (relative humidity)5 to 95% Note: Not to exceed 0.024 kg of water per kg of dry air
Reliability and availabilityLine card Online Insertion and Removal (OIR) support without system impact
Network Equipment Building Systems (NEBS)Designed to meet: ● SR-3580: NEBS Criteria Levels (Level 3) ● GR-1089-CORE: NEBS EMC and Safety ● GR-63-CORE: NEBS Physical Protection
Operating humidity (nominal) (relative humidity)10 to 85%
Physical dimensions(includes ejector bracket/lever); (H x W x D); weight2T Service Edge Combo Line Card - 5th Generation: 1.63 x 15.58 x 23.80 in.; 24.15 lb (41.4 x 395.7 x 604.5 mm; 10.95 kg) 2T Packet Transport Combo Line Card - 5th Generation: 1.63 x 15.58 x 23.80 in.; 24.15 lb (est.) (41.4 x 395.7 x 604.5 mm; 10.95 kg) 800G Service Edge Combo Line Card - 5th Generation: 1.63 x 15.58 x 23.80 in.; 21.70 lb (41.4 x 395.7 x 604.5 mm; 9.84 kg) 800G Packet Transport Combo Line Card - 5th Generation: 1.63 x 15.58 x 23.80 in.; 21.70 lb (41.4 x 395.7 x 604.5 mm; 9.84 kg)
Warranty3-Year Warranty

Key Features

  • OEM Genuine Component verified by certified technicians.
  • Clean serial number ready for service contract registration.
  • Electrostatic Discharge (ESD) safe packaging.
  • Supports hot-swapping for zero-downtime maintenance.

Frequently Asked Questions

Is this product genuine OEM?

Yes, this A9K-4HG-FLEX-TR, Cisco ASR 9000 Router, 4x100GE/400G, Flexible Interface, No Fan & PSU (CIS:A9K-4HG-FLEX-TR) is 100% genuine OEM hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.

What warranty is included?

This A9K-4HG-FLEX-TR, Cisco ASR 9000 Router, 4x100GE/400G, Flexible Interface, No Fan & PSU includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.

How long does shipping take?

We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.

Can I return this product?

Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.

Is the A9K-4HG-FLEX-TR, Cisco ASR 9000 Router, 4x100GE/400G, Flexible Interface, No Fan & PSU compatible with my system?

Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the CIS:A9K-4HG-FLEX-TR.
