Cisco Catalyst 9300X 24-Port 10G Multigigabit UPoE+ Network Switch
Brand: Cisco · SKU: C9300X-24HX · MPN: C9300X-24HX · Category: Networking
The Cisco Catalyst 9300X is a high-performance, stackable enterprise access switch engineered to meet the evolving demands of modern hybrid networks, supporting Wi-Fi 6, 802.11ac Wave 2, IoT integration, mobility, and cloud readiness. It features 24x 10 Gigabit Ethernet UPoE+ (802.3bt 90W) RJ45 ports and one dedicated expansion module slot for flexible uplinks, making it suitable for demanding network environments. Built on the advanced UADP 2.0sec ASIC, it natively supports 100G hardware-based IPsec for robust security and secure tunnel connectivity. The switch offers industry-leading stacking bandwidth of up to 1 Tbps with StackWise-1T technology, allowing for up to 8 members in a single stack, and integrates StackPower+ for enhanced power resiliency. It provides a substantial Power over Ethernet (PoE) budget of up to 735W with the default 1100W AC power supply, which can be further expanded with an optional second power supply to meet high-density PoE requirements. Running on Cisco
Specifications
| CPU | x86 CPU complex |
|---|---|
| ASIC | UADP 2.0sec |
| DRAM | 16 GB |
| Software | Cisco IOS XE, requires Cisco DNA Advantage/Essentials subscription |
| Fan Modules | 3x FAN-T2 Fan Modules Included |
| Flash Memory | 16 GB |
| Layer Support | Layer 2, Layer 3 |
| Network Ports | 24x 10 Gigabit Ethernet UPoE+ RJ45 (UPOE+ - 802.3bt 90W) |
| Stacking Ports | 2x StackWise-1T, 2x StackPower+ |
| Forwarding Rate | 327.38 Mpps |
| Management Ports | 1x USB 2.0, 1x RJ45 Management |
| Airflow Direction | Front-to-Back Airflow (Port Side Intake) |
| Max Stack Members | 8 |
| Security Features | 100G hardware-based IPsec, Secure Tunnel connectivity, Cisco TrustSec |
| Stacking Bandwidth | Up to 1 Tbps (StackWise-1T) |
| Switching Capacity | 880 Gbps |
| Expansion Module Slots | 1 |
| MAC Address Table Size | 32,000 entries |
| Power Supply (Default) | 1x PWR-C1-1100WAC-P PSU (included), 2nd PSU slot available |
| PoE Budget (Default PSU) | 735W |
| PoE Budget (Max with 2nd PSU) | Up to 1835W (with 1100W 2nd PSU) |
| Warranty | Limited Lifetime Warranty |
| Dimensions | 1.73 x 17.5 x 17.5 in (H x W x D) |
Key Features
The Cisco Catalyst 9300X is a leading enterprise access switching platform in the Catalyst 9000 family, engineered to support evolving network demands for hybrid workforces, IoT, and cloud. It delivers industry-leading stacking bandwidth of up to 1 Tbps with StackWise-1T, dense Multigigabit and 90W UPOE+ port density, and flexible modular uplinks. Integrated with the UADP 2.0sec ASIC, it provides hardware-based 100G IPsec encryption for enhanced security. The switch offers power resiliency with StackPower+ and supports advanced Layer 2/3 features, QoS, and ACLs, all manageable via Cisco IOS XE and integral to Cisco's Software-Defined Access architecture.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this Cisco Catalyst 9300X 24-Port 10G Multigigabit UPoE+ Network Switch (C9300X-24HX) is 100% genuine Cisco hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This Cisco Catalyst 9300X 24-Port 10G Multigigabit UPoE+ Network Switch includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the Cisco Catalyst 9300X 24-Port 10G Multigigabit UPoE+ Network Switch compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the C9300X-24HX.
