Cisco Catalyst 9200 Network Essentials 48 Port L3 Gigabit Data Switch C9200-48T-E
Brand: Cisco · SKU: C9200-48T-E · MPN: C9200-48T-E · Category: Networking
The Cisco Catalyst C9200-48T-E is a high-performance, enterprise-class fixed configuration switch designed for secure, scalable access in branch, campus, and midsize IT infrastructures. It offers 48x 1GB RJ45 data-only ports and operates with the Network Essentials software license. It supports Layer 3 routing features and optional backplane stacking (StackWise-160) up to 9 units with stacking bandwidth up to 160 Gbps. It features modular uplink options and supports optional 1+1 power supply redundancy and hot-swappable fan trays for resiliency. It leverages the UADP 2.0 Mini ASIC and supports Cisco IOS XE.
Specifications
| DRAM | 4 GB |
|---|---|
| Security | ACLs (32,000 hardware entries), 802.1X, AES-128 MACsec encryption |
| Flash Memory | 4 GB |
| Uplink Ports | Modular uplink options (e.g., 4 × 1G SFP or 4 × 10G SFP+ via network modules) |
| VLAN Support | 4096 active VLANs |
| Buffer Memory | 16 MB shared or 6 MB per SKU |
| License Level | Network Essentials (E) |
| PoE Capability | Data Only (No PoE/PoE+) |
| Forwarding Rate | 72 Mpps or 261.9 Mpps (depending on reference/configuration) |
| Layer Supported | 3 |
| Port Configuration | 48 × 10/100/1000BASE-T (RJ45) |
| Stacking Bandwidth | Up to 160 Gbps (with StackWise-160) |
| Default Power Supply | PWR-C6-125WAC |
| Operating Temperature | 32°F to 104°F (0°C to 40°C); Short-term up to 50°C |
| MAC Address Table Size | 32,000 entries |
| Routing Protocols Supported | Static, RIPv1/v2, OSPF, EIGRP, limited BGP support |
| Total Number of Network Ports | 48 |
| Switching Capacity (Non-stacked) | 96 Gbps or 176 Gbps (depending on reference/configuration) |
| Warranty | Warranty and Terms provided exclusively by the manufacturer. |
| Weight | 5 kg |
| Dimensions | 1.73 x 17.5 x 13.8 in (Chassis Dimensions, Base Unit); 4.4 x 44.5 x 35.0 cm |
Key Features
The Cisco Catalyst 9200-48T-E is a 48-port Gigabit Ethernet switch part of the Catalyst 9200 Series, running the Network Essentials license. It is designed as a data-only switch, meaning it does not support Power over Ethernet (PoE). It provides Layer 3 capabilities, supports StackWise-160 stacking for high density, and is built on the Cisco DNA Architecture for simplified management, security, and automation.
