BC1M04SRSC, Huawei RH2285V2 Server, 2xE5-2407 CPU/2x8GB Mem/2x300GB SAS

Brand: Huawei · SKU: BC1M04SRSC · MPN: BC1M04SRSC · Category: Components

BC1M04SRSC, Huawei RH2285V2 Server, 2xE5-2407 CPU/2x8GB Mem/2x300GB SAS
$1,181.28
In Stock • 10 units

Huawei BC1M04SRSC RH2285V2 8HD Model(2*E5-2407 CPU,2*8GB Mem,2*300GB SAS,DVD-RW,6*GE,SR320BC,2*460W AC PS)

View Processors Products

Specifications

PSU2 hot-swappable 1+1 redundant PSUs: • AC: 460W or 800W • –48 V DC: 800W
ModelBC1M04SRSC
Memory12 DDR3 RDIMMs/LRDIMMs, up to 384GB
Weight19.73 kg
USB port6 (front: 2, rear: 2, built-in: 2)
ProcessorIntel® Xeon® E5-2400 series Core options: 4, 6, or 8 Maximum dominant frequency: 2.4GHz(6 Cores) or 2.3GHz (8 Cores) L3 cache: 20MB
DimensionsHeight: 87.5mm (3.44in.) Width: 447mm (17.60in.) Depth: 740mm (29.13in.)
Fan module4 hot-swappable counter-rotating fan modules in N+1 redundancy mode
ManagementUEFI Huawei iMana, support IPMI, SOL, KVM over IP, and virtual media One 10/100 Mbit/s RJ45 management network port
Form factor2U rack server
Power supply110 V/220 V AC or –48 V DC
RAID supportRAID 0, 1, 10, 5, 50, 6, and 60 RAID cache: 512MB or 1GB Power-off protection: • BBU (3 x 24 hours) • Supercapacitor
Expansion slotUp to 5 PCIe 3.0 slots 1 processor: • 1 PCIe 3.0 x8 •1 PCIe 3.0 x4 • 1 PCIe slot for a RAID controller card 2 processors: • 1 PCIe 3.0 x8 • 1 PCIe 3.0 x4 • 1 PCIe slot for a RAID controller card • (Optional) 1 PCIe 3.0 x16 • (Optional) 1 PCIe 3.0 x8
Internal storageOptions: • 8 x 2.5" SAS/SATA HDDs or SSDs, up to 8TB • 12 x 3.5" SAS/SATA HDDs and 2 x 2.5" SAS/SATA HDDs or SSDs, up to 38TB • 26 x 2.5" SAS/SATA HDDs or SSDs, up to 26TB
LOM network port2 onboard GE ports
Number of processors1 or 2
Operating temperature5ºC–40ºC (41ºF–104ºF)
Operating systems supportedMicrosoft Windows Server Red Hat Enterprise Linux SUSE Linux Enterprise Server CentOS Solaris Oracle Enterprise Linux / Oracle Server VM Citrix XenServer VMware ESX / VMware ESX i
Warranty3-Year Warranty

Key Features

  • OEM Genuine Component verified by certified technicians.
  • Clean serial number ready for service contract registration.
  • Electrostatic Discharge (ESD) safe packaging.
  • Supports hot-swapping for zero-downtime maintenance.

Frequently Asked Questions

Is this product genuine OEM?

Yes, this BC1M04SRSC, Huawei RH2285V2 Server, 2xE5-2407 CPU/2x8GB Mem/2x300GB SAS (BC1M04SRSC) is 100% genuine Huawei hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.

What warranty is included?

This BC1M04SRSC, Huawei RH2285V2 Server, 2xE5-2407 CPU/2x8GB Mem/2x300GB SAS includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.

How long does shipping take?

We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.

Can I return this product?

Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.

Is the BC1M04SRSC, Huawei RH2285V2 Server, 2xE5-2407 CPU/2x8GB Mem/2x300GB SAS compatible with my system?

Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the BC1M04SRSC.
