AMD Socket AM2 (940-Pin PGA)
Brand: AMD · SKU: AMD-SKT-AM2 · MPN: AM2 · Category: Components
The AMD Socket AM2, originally codenamed Socket M2, is a 940-pin CPU socket designed by AMD for desktop processors including the performance, mainstream, and value segments. Released on May 23, 2006, it served as the successor to Socket 939 and Socket 754. The primary innovation of the AM2 platform was the transition from DDR to DDR2 SDRAM memory support, utilizing an integrated memory controller within the processor. It features a 940-pin organic micro Pin Grid Array (µPGA) package and employs HyperTransport 2.0 technology for high-speed system bus communication. Although it shares the same pin count as the server-grade Socket 940, it is electrically and mechanically incompatible with it. Socket AM2 supports a wide array of processors including the Athlon 64, Athlon 64 X2, Athlon 64 FX, and Sempron series, as well as early Phenom processors through backward compatibility (subject to motherboard BIOS updates).
Specifications
| Pin Count | 940 |
|---|---|
| Pin Pitch | 1.27 mm |
| Socket Type | PGA-ZIF (Zero Insertion Force) |
| Release Date | May 23, 2006 |
| Bus Interface | HyperTransport 2.0 (1000 MHz / 2000 MT/s) |
| Memory Support | DDR2 SDRAM (up to 800 MHz) |
| Heatsink Mounting | 48mm x 96mm rectangular bracket |
| Process Technology | 90nm / 65nm |
| Warranty | Not Available (Legacy Product) |
| Weight | 0.05 kg |
| Dimensions | 40mm x 40mm |
Key Features
AMD Socket AM2 was a pivotal transition for AMD, bringing DDR2 memory and standardized cooling solutions to the desktop market. It consolidated various processor lines into a single socket interface, streamlining the motherboard ecosystem for both single-core and dual-core Athlon 64 and Sempron processors.
Technical Deployment Advisory
Target Personnel
Field Engineers
Infrastructure Fit
Server Fleet Uniformity
"As a genuine AMD component, the AMD-SKT-AM2 ensures 100% compatibility for Server Fleet Uniformity. It is an essential part for Field Engineers tasked with hardware lifecycle maintenance."
Frequently Asked Questions
Is this product genuine OEM?
Yes, this AMD Socket AM2 (940-Pin PGA) (AMD-SKT-AM2) is 100% genuine AMD hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This AMD Socket AM2 (940-Pin PGA) includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the AMD Socket AM2 (940-Pin PGA) compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the AMD-SKT-AM2.
