AIR-AP1815I-T-K9, Cisco Aironet 1815i Access Point, 802.11ac Wave2/2x2 MIMO/Gigabit Ethernet
Brand: Cisco · SKU: AIR-AP1815I-T-K9 · MPN: AIR-AP1815I-T-K9 · Category: Networking
Request for Quote
In Stock • 10 units
Cisco Aironet 1815i Series, Reg Domain T
Specifications
| Note | Maximum channel numbers, operating power, and spectrum vary by regulatory domain; consult documentation for details |
|---|---|
| Model | AIR-AP1815I-T-K9 |
| Mounting | Includes mounting bracket AIR-AP-BRACKET8 |
| Software | Cisco Unified Wireless Network Software with AireOS Wireless Controllers Release 8.5 or later, Cisco Mobility Express |
| Bluetooth | Integrated Bluetooth 4.1 (BLE), max transmit power: 4 dBm, antenna gain: 2 dBi |
| Compliance | Safety: UL 60950-1, CAN/CSA-C22.2 No. 60950-1, UL 2043, IEC 60950-1, EN 60950-1 Radio: FCC Part 15.247/15.407/15.107/15.109, RSS-247, EN 300.328/301.893/301.489-1/-17, ARIB-STD 66/T71, ICES-003, VCCI, EN 50385 IEEE Standards: 802.11a/b/g, 802.11n, 802.11h, 802.11d, 802.11ac Security: 802.11i, WPA2, WPA, 802.1X, AES EAP Types: TLS, TTLS/MSCHAPv2, PEAP v0/v1, GTC, FAST, SIM Multimedia: Wi-Fi Multimedia (WMM) Other: FCC OET-65C, RSS-102 |
| Indicators | Status LED for boot loader, association, operational states, warnings, and errors |
| Power Draw | 8.3 W (maximum, on PoE) |
| Accessories | Spare bracket: AIR-AP-BRACKET8=; Security kit (sold separately): AIR-SEC-50=, including 50 security screws, 50 RJ-45 caps, 2 unlock keys |
| Ethernet Ports | 1 x 10/100/1000BASE-T (RJ-45, PoE), authentication with 802.1X or MAC filtered, dynamic VLAN or per port, local switch or tunnel to controller; Management console port (RJ-45) |
| Maximum Clients | 200 per Wi-Fi radio, up to 400 per access point |
| Powering Options | 802.3af/at PoE switch, optional Cisco injectors (AIR-PWRINJ5=, AIR-PWRINJ6=) |
| System Resources | 1 GB DRAM, 256 MB Flash, 710 MHz quad-core CPU |
| Physical Security | Includes Torx security screw |
| Integrated Antennas | 2.4 GHz: 2 dBi gain; 5 GHz: 4 dBi gain |
| 802.11ac Performance | 2x2 SU/MU-MIMO, two spatial streams, maximal ratio combining (MRC), 20/40/80 MHz channels, PHY data rates up to 866.7 Mbps (80 MHz at 5 GHz), packet aggregation (A-MPDU/A-MSDU), 802.11 DFS, cyclic shift diversity support |
| Supported Data Rates | 802.11a: 6/9/12/18/24/36/48/54 Mbps; 802.11b/g: 1/2/5.5/6/9/11/12/18/24/36/48/54 Mbps; 802.11n (2.4 GHz): up to 144.4 Mbps per stream; 802.11ac (5 GHz): up to 866.7 Mbps |
| Operating Environment | Operating: 0°C to 40°C (32°F to 104°F), 10%–90% humidity (non-condensing), up to 3000 m altitude; Storage/transport: −30°C to 70°C (−22°F to 158°F), 10%–90% humidity (non-condensing), up to 4500 m altitude |
| Dimensions (W x L x H) | 6 x 6 x 1.3 in (150.8 x 150.8 x 33 mm) without bracket |
| 802.11ac MCS Data Rates | Fully supports MCS 0-9, up to two spatial streams, 20/40/80 MHz bandwidth; refer to full table for detailed Mbps rates |
| Transmit Power Settings | 2.4 GHz: 20/17/14/11/8/5/2/−1 dBm (100/50/25/12.5/6.25/3.13/1.56/0.78 mW); 5 GHz: 20/17/14/11/8/5/2/−1 dBm (100/50/25/12.5/6.25/3.13/1.56/0.78 mW) |
| Input Power Requirements | Requires power injector: AIR-PWRINJ5= or AIR-PWRINJ6= |
| Supported WLAN Controllers | Cisco 2500/3500/5500/7500/8500/9800 Series Wireless Controllers, Cisco Wireless Controller Module for ISR G2, Cisco Wireless Services Module 2 (WiSM2) for Catalyst 6500 Series Switches, Cisco Mobility Express |
| Authentication and Security | Advanced Encryption Standard (AES) for WPA2, 802.1X, RADIUS authentication, authorization and accounting (AAA), 802.11r, 802.11i |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
