Cisco Aironet 5GHz 3.5dBi Articulated Dipole Antenna with RP-TNC Connector (Black)
Brand: Cisco · SKU: AIR-ANT5135D-R · MPN: AIR-ANT5135D-R · Category: Networking
The Cisco AIR-ANT5135D-R is a 3.5-dBi Articulated Dipole Antenna that operates in the 5-GHz frequency band. It is designed for use with Cisco Aironet 5-GHz radio products that utilize a Reverse-Polarity TNC (RP-TNC) connector. The antenna features an articulated base allowing 360-degree rotation at the connection point and 0 to 90 degrees at its knuckle with detents at 45 and 90 degrees. The radome color for this model (AIR-ANT5135D-R) is Black. It is suitable for indoor, omnidirectional coverage applications within a Wireless Data Network. Maximum estimated range is 675 ft under ideal conditions with a client adapter.
Specifications
| Directivity | Omni-directional |
|---|---|
| Antenna Gain | 3.5 dBi or 4 dB |
| Polarization | Linear, vertical |
| Product Line | Aironet |
| Product Type | Antenna |
| Radome Color | Black |
| Connector Type | RP-TNC (Reverse-Polarity TNC) |
| 2:1 VSWR Bandwidth | 5150 to 5850 MHz |
| Frequency Band Type | SHF |
| Storage Temperature | -40°F to 185°F. (–40°C to 85°C) |
| Operating Temperature | -22°F to 158°F. (–30°C to 70°C) |
| E-plane 3-dB Beamwidth | 40 degrees |
| H-plane 3-dB Beamwidth | Omnidirectional |
| Nominal Input Impedance | 50Ω |
| Operating Frequency Range | 5.15 GHz to 5.85 GHz |
| Warranty | 90-day warranty (for some refurbished/new listings), 1 Year Limited Warranty (listed in one table) |
| Weight | 1 oz (Approximate) or 5.00 LBS |
| Dimensions | Height: 5.3", Width: 0.6" |
Key Features
Cisco Aironet 3.5-dBi Articulated Dipole Antenna operating in the 5-GHz band with an RP-TNC connector, designed for indoor omnidirectional coverage. The antenna is articulated for flexible positioning.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this Cisco Aironet 5GHz 3.5dBi Articulated Dipole Antenna with RP-TNC Connector (Black) (AIR-ANT5135D-R) is 100% genuine Cisco hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This Cisco Aironet 5GHz 3.5dBi Articulated Dipole Antenna with RP-TNC Connector (Black) includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the Cisco Aironet 5GHz 3.5dBi Articulated Dipole Antenna with RP-TNC Connector (Black) compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the AIR-ANT5135D-R.
