MSI 945P NEO-F motherboard LGA 775 (Socket T) ATX
Brand: MSI · SKU: 945P NEO-F · MPN: 945P NEO-F · Category: Components
MSI 945P NEO-F, Intel, LGA 775 (Socket T), 1066 MHz, 4 GB, Intel 82573 PCI-E 1 Gb LAN, ATX. MSI 945P NEO-F motherboard LGA 775 (Socket T) ATX (part number 945P NEO-F) is an enterprise components product available from Server Tech Central. Key specifications include audio output 7.1 Realtek ALC882., expansion slots 1x PCI Express x16 2x PCI Express x1 3x 32-bit v2.3 master PCI, processor socket LGA 775 (Socket T), power source type ATX, networking features Intel 82573 PCI-E 1 Gb LAN, processor manufacturer Intel, maximum internal memory 4 GB, motherboard form factor ATX. Every unit is fully tested and backed by our standard 3-Year Warranty, with free US ground shipping and same-day dispatch on in-stock orders. Volume pricing and Net-30 terms are available for qualified businesses, government, and education.
Specifications
| I/O ports | 1 x Parallel port 1 x Serial port (COM 1) 1 x PS/2 keyboard 1 x PS/2 mouse 1 x Coaxial SPDIF out 1 x 6 in 1 audio jack (S/SPDIF out) 4 x USB 2.0 ports 1 x RJ45 LAN jacks |
|---|---|
| Audio output | 7.1 Realtek ALC882. |
| Expansion slots | 1x PCI Express x16 2x PCI Express x1 3x 32-bit v2.3 master PCI |
| Processor socket | LGA 775 (Socket T) |
| Power source type | ATX |
| Networking features | Intel 82573 PCI-E 1 Gb LAN |
| Processor manufacturer | Intel |
| Maximum internal memory | 4 GB |
| Motherboard form factor | ATX |
| Processor system buses supported | 1066 MHz |
| Warranty | 3-Year Warranty |
Product Description
Supports Socket 775 for Intel® P4 5XX, 6XX, P4EE, Pentium D 8XX and Celeron D processors. Supports FSB 1066/800/533MHz. Supports EIST technology. Supports Intel® Hyper-Threading technology. Supports Intel® Dual Core Technology to 800MHz and up. Intel® 945P Chipset - Supports FSB 533/800/1066MHz. - Supports PCI Express x 16 graphics interface. - Supports dual channel, DDR2 400/533/667 Intel® ICH7 Chipset - Hi-Speed USB (USB2.0) controller, 480Mb/sec, up to 8 ports. - 4 SATAII ports with transfer rate up to 3Gb/s. - 1 channel Ultra ATA 100 bus master IDE controller. - PCI Master v2.3, I/O APIC. - ACPI 2.0 compliant. - Integrated AHCI controller. Supports four unbuffered DIMM of 1.8 Volt DDRII SDRAM Supports up to 4GB memory size. Supports dual channel DDRII memory architecture. Supports DDRII 533/667 memory interface. One PCI Express x16 slot. (supports PCI Express Bus specification v1.0a compliant) Two PCI Express x1 slots. (support PCI Express Bus specification v1.0a compliant) Three 32-bit v2.3 master PCI bus slots. (support 3.3v/5v PCI bus interface) On-Board IDE/SATA One Ultra DMA 66/100 IDE controllers integrated in ICH7. - Supports PIO, Bus Master operation modes. - Can connect up to two Ultra ATA drives. SATAII controller integrated in ICH7 - Up to 300MB/sec transfer speed. - Can connect up to four SATAII devices. High Definition link controller integrated in Intel® ICH7 chip. Audio codec Realtek® ALC882. - Compliant with Azalia 1.0 spec. - Supports DTS effect. Intel® 82573 PCI-E Gb LAN - Supports 10 / 100 / 1000 Mb/s. - Compliane with PCI 2.2. - Supports ACPI Power Management. Internal I/O Connectors - ATX 24-Pin power connector - 4-pin VGA power connector - 8-pin ATX 12V power connector - CPU / System / Power / NB FAN connectors - CD-in connector - Clear CMOS jumper - Chassis intrusion switch connector - Front panel audio connector - Front panel connector - 2 x USB 2.0 connector support additional 4 ports - 1 x Floppy disk drive connector - 4 x Serial ATA connectors - 1 x ATA100 HD connectors
Key Features
MSI 945P NEO-F. Processor manufacturer: Intel, Processor socket: LGA 775 (Socket T), Processor system buses supported: 1066 MHz. Maximum internal memory: 4 GB. Networking features: Intel 82573 PCI-E 1 Gb LAN. Motherboard form factor: ATX, Power source type: ATX. Audio output: 7.1 Realtek ALC882.
