Brand: HPE (Hewlett Packard Enterprise) · SKU: 6120XG · MPN: 6120XG · Category: Networking
The HPE 6120XG Blade Switch is a high-performance, highly reliable Ethernet switch designed for the c-Class BladeSystem and HPE Integrity Superdome 2 enclosures. It features sixteen 10Gb downlinks and eight 10G SFP+ uplinks (including a dual personality CX4 and SFP+ 10G uplink, and two 10Gb cross-connects). It offers a robust set of industry-standard enhanced Layer 2 switching functions, QoS metering, security, and High Availability features. It is suited for datacenters migrating to 10G high-performance architectures, providing future-proofing with support for dual speed on 10G uplinks and Converged Enhanced Ethernet (CEE) capability. Management options include CLI, Web, Telnet, OOBM via an onboard administrator or mini USB console port, and SNMP via PCM/M+.
| QoS | Classify data into 2, 4, or 8 hardware priority queues based on 802.1p CoS |
|---|---|
| VLAN | 802.1Q support |
| Memory | 512 MB Main, 640MB flash, 2MB packet buffer |
| Latency | 1.8uS (64-byte packets) (store and forward) |
| Uplinks | 8 x 10G SFP+ (SR, LR, or LRM fiber/copper), 1 x 10Gb CX4 (Copper) |
| Trunking | 802.3ad (LACP), compatible with Cisco Etherchannel® |
| Downlinks | 16 x 10Gb (to server NICs) |
| Throughput | 480Gb total throughput; 80 Gbps external port bandwidth per BladeSystem enclosure (160 Gbps full duplex) |
| Form Factor | Plug-in module for c-Class BladeSystem/Integrity Superdome 2 |
| MAC Addresses | Supports 16K MAC addresses per switch |
| Spanning Tree | 802.1D, 802.1w (RSTP), 802.1s (MSTP). Up to 16 STGs supported. |
| Cross Connects | 2 x 10Gb (for redundancy) |
| Forwarding Mode | Configurable for Store and Forward or Cut Through |
| Forwarding Rate | 357.1 million pps (64-byte packets) |
| Multicast Groups | 256 |
| Power Consumption | 105 Watt Operational |
| Security Features | Port security (802.1x, web, MAC auth), SSH, HTTPS (SSL), SFTP, RADIUS, TACACS+, MAC address lockout, STP root guard. |
| Power Requirements | 12V @ 8.75A (105 W) (per interconnect switch) |
| Jumbo Frame Support | 9220 Byte |
| Operating Temperature | 10° to 35° C (50° to 95° F) |
| Warranty | Varies (Some results indicate 90 Days for used/refurbished units; original warranty support status may be affected as the product is retired) |
| Weight | 1.27 kg (2.8 lbs) |
| Dimensions | Length: 13.88 in (352.55 mm), Width: 10.63 in (270.00 mm), Height: 4.75 in (120.65 mm) |
The HPE 6120XG Blade Switch is a highly capable switch designed specifically for the HP c-Class BladeSystem enclosure, optimized for datacenters migrating to 10G high-performance architectures. It provides resilient core-to-edge connectivity, automated provisioning, and investment protection through features like CEE capability and dual-speed 10G uplinks. It includes a comprehensive set of Layer 2, QoS, and security features.
Yes, this HPE 6120XG Blade Switch (6120XG) is 100% genuine HPE (Hewlett Packard Enterprise) hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
This HPE 6120XG Blade Switch includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the 6120XG.
