Lenovo 256MB ATI X1300 Dual-VGA or Dual-DVI, TV-out PCI-Express Graphics Adapter GDDR2
Brand: Lenovo · SKU: 41U5028 · MPN: 41U5028 · Category: Components
Lenovo 256MB ATI X1300 Dual-VGA or Dual-DVI, TV-out PCI-Express Graphics Adapter, GDDR2, 64 bit, 2560 x 1600 pixels. Lenovo 256MB ATI X1300 Dual-VGA or Dual-DVI, TV-out PCI-Express Graphics Adapter GDDR2 (part number 41U5028) is an enterprise components product available from Server Tech Central. Key specifications include depth 21 mm, height 69 mm, length 168 mm, tv-out Yes, weight 430 g, dual vga Yes, memory bus 64 bit, dual link dvi Yes. Every unit is fully tested and backed by our standard 3-Year Warranty, with free US ground shipping and same-day dispatch on in-stock orders. Volume pricing and Net-30 terms are available for qualified businesses, government, and education.
Specifications
| Depth | 21 mm |
|---|---|
| Height | 69 mm |
| Length | 168 mm |
| TV-out | Yes |
| Weight | 430 g |
| Dual VGA | Yes |
| Memory bus | 64 bit |
| Dual Link DVI | Yes |
| DirectX version | 9.0 |
| Mac compatibility | No |
| Maximum resolution | 2560 x 1600 pixels |
| Graphics card RAMDAC | 400 MHz |
| Shader model version | 3.0 |
| Graphics card memory type | GDDR2 |
| Operating temperature (T-T) | 0 - 50 °C |
| Compatible operating systems | Windows XP, Windows 2000 SP 4 |
| Operating relative humidity (H-H) | 5 - 85% |
| Warranty | 3-Year Warranty |
| Weight | 430 g |
| Dimensions | 21 mm x 69 mm |
Product Description
ThinkCentre and Lenovo users can now experience superior image quality and improved overall system performance by installing the Lenovo ATI X1300 256MB Dual-VGA/Dual-DVI TV-Out PCI Express Dual Head Graphic Adapter. It improves performance and helps increase productivity whenever users need to work with graphic-intensive software for desktop publishing, animation, presentations and other multimedia formats, or need to view multiple applications displayed across two monitors. Users also benefit from the improved image filtering a dedicated graphics adapter can deliver, such as smoothing jagged edges and stair-like effects and removing or reducing blocky artifacts (dropout and jagged edges). Features & Benefits: - Dual-VGA or Dual-DVI via the DMS-59 connector, and TV-out (s video) connection - A low-profile adapter with native PCI-e x16 bus interface with a fitted full-height bracket - Attach two monitors for multi-monitoring environments using Dual-VGA or Dual-DVI - Dual-link DVI-I for high-resolution digital monitors - Includes a Low-profile bracket - 10-bit color for over 1.037 billion displayable colors - 2560 x 1600 maximum PC monitor resolution - 1024 x 768 TV-out resolution - 64-bit DDR2 memory interface - 256MB of video memory - Includes a DMS59 Dual-VGA dongle and a DMS59 Dual-DVI dongle - Dual integrated 400 MHz DACs - 165 MHz TMDS transmitter.
Key Features
Lenovo 256MB ATI X1300 Dual-VGA or Dual-DVI, TV-out PCI-Express Graphics Adapter. Graphics card memory type: GDDR2, Memory bus: 64 bit. Maximum resolution: 2560 x 1600 pixels. DirectX version: 9.0, Dual Link DVI
Frequently Asked Questions
Is this product genuine OEM?
Yes, this Lenovo 256MB ATI X1300 Dual-VGA or Dual-DVI, TV-out PCI-Express Graphics Adapter GDDR2 (41U5028) is 100% genuine Lenovo hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This Lenovo 256MB ATI X1300 Dual-VGA or Dual-DVI, TV-out PCI-Express Graphics Adapter GDDR2 includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the Lenovo 256MB ATI X1300 Dual-VGA or Dual-DVI, TV-out PCI-Express Graphics Adapter GDDR2 compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the 41U5028.
