Brand: MGT (Manufacturer Group of Technology) · SKU: 37MGT · MPN: 37MGT · Category: Components
The MGT 37 Series is a General Purpose Silicon (Si) MOSFET Relay available in DIP and SMD types, featuring one or two channels. It is designed to switch AC or DC loads and has an input compatible with TTL/CMOS logic levels. The relays are UL 1577 approved (File no E344988) and have a Moisture Sensitivity Level (MSL) of 3. Key specifications include a maximum Load Voltage (VL) of 60V, an Operation LED Current (IF ON) of 3mA, a Load Current (IL) of 550mA, and an On-Resistance (RON) of 0.75Ω. The Off-State Leakage Current (ILEAK) is rated at 1µA at 60VDC, and the Output Capacitance (COUT) is 45pF. Applications include Automatic Test Equipment, I/O Modules, Industrial Automation, Measurement Equipment, Security Equipment, and Telecom Equipment.
| Series | 37 |
|---|---|
| Relay Type | General Purpose Si MOSFET Relay |
| Contact Form | 1 Form A / 2 Form A (Normally open switch) |
| Certification | UL 1577 approved (File no E344988) |
| Package Types | DIP and SMD types available |
| Load Current (IL) | 550mA |
| Load Voltage (VL) | 60V |
| Input Compatibility | TTL / CMOS |
| On-Resistance (RON) | 0.75Ω |
| Output Capacitance (COUT) | 45pF |
| Off-State Leakage Current (ILEAK) | 1µA at 60VDC |
| Warranty | Not specified in search result. Refer to manufacturer policy. |
| Weight | Unknown |
| Dimensions | Varies by package type (DIP-4, SMD-4, DIP-6, SMD-6, DIP-8, SMD-8, SOP-4, SOP-8). Dimensions detailed in datasheet for each package. |
The MGT 37 Series is a family of general-purpose solid-state relays utilizing Silicon MOSFET technology. They are designed for low-power switching applications in various electronic systems, featuring low on-resistance and low leakage current.
Yes, this MGT 37 Series General Purpose Si MOSFET Relay (37MGT) is 100% genuine MGT (Manufacturer Group of Technology) hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
This MGT 37 Series General Purpose Si MOSFET Relay includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the 37MGT.
