Brand: Baldor-Reliance · SKU: 3710T · MPN: M3710T · Category: Components
The M3710T is a 7.5 HP, 3-phase, 60 Hz, 1800 RPM (1770 RPM base) general purpose motor with a 213T Frame size and TEFC enclosure. It is designed for continuous duty and is suitable for mounting in any position, featuring ball bearings, heavy-gauge steel and cast-iron frames. This model appears to be discontinued, with EM3710T listed as an alternate catalog number for the NEMA Premium efficiency version. The specification sheet for the M3710T lists NEMA Nom. Eff. of 89.5% and a Service Factor of 1.15.
| Phase | 3 Phase |
|---|---|
| Voltage | 208-230/460 V |
| Frequency | 60 Hz |
| IP Rating | IP44 |
| Base Speed | 1770 RPM |
| Frame Size | 213T |
| Horsepower | 7.5 HP |
| Duty Rating | Continuous Duty (CONT) |
| Catalog Number | M3710T |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Service Factor | 1.15 |
| Shaft Diameter | 1.375 IN |
| Insulation Class | F |
| NEMA Design Code | A |
| Synchronous Speed | 1800 RPM |
| Mounting Arrangement | F1 (Foot Mount) |
| NEMA Nominal Efficiency | 89.5 % |
| Alternate Catalog Number | EM3710T |
| Full Load Current (460V) | 10.1 A |
| Warranty | 3 Year Warranty (for the comparable EM3710T model). |
| Weight | 120.000 LB |
| Dimensions | Not explicitly provided for M3710T, but shipping dimensions for a similar item are 14 x 26 x 14 inches. |
The Baldor M3710T is a discontinued 7.5 HP, 3-phase, 60 Hz general-purpose motor with a 213T frame. It features a TEFC enclosure and is built with ball bearings and heavy-gauge steel/cast-iron frames, making it suitable for general industrial applications like pumps, fans, and conveyors. Its alternate, the EM3710T, is a NEMA Premium efficiency version.
Yes, this Baldor-Reliance M3710T General Purpose Motor (Discontinued, Alternate EM3710T) (3710T) is 100% genuine Baldor-Reliance hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
This Baldor-Reliance M3710T General Purpose Motor (Discontinued, Alternate EM3710T) includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the 3710T.
