ATEN VGA EDID Emulator
Brand: ATEN · SKU: 2A-130G · MPN: 2A-130G · Category: Components
ATEN VGA EDID Emulator, 0.35 m, USB Type-A, VGA (D-Sub), Male, Male, Straight. ATEN VGA EDID Emulator (part number 2A-130G) is an enterprise components product available from Server Tech Central. Key specifications include depth 65.9 mm, width 34 mm, height 16 mm, weight 40 g, connector 1 USB Type-A, connector 2 VGA (D-Sub), cable length 0.35 m, package depth 245 mm. Every unit is fully tested and backed by our standard 3-Year Warranty, with free US ground shipping and same-day dispatch on in-stock orders. Volume pricing and Net-30 terms are available for qualified businesses, government, and education.
Specifications
| Depth | 65.9 mm |
|---|---|
| Width | 34 mm |
| Height | 16 mm |
| Weight | 40 g |
| Connector 1 | USB Type-A |
| Connector 2 | VGA (D-Sub) |
| Cable length | 0.35 m |
| Package depth | 245 mm |
| Package width | 205 mm |
| Package height | 20 mm |
| Package weight | 52 g |
| Product colour | Blue, Silver |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Maximum resolution | 1920 x 1200 pixels |
| Maximum refresh rate | 60 Hz |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Master (outer) case width | 212 mm |
| Storage temperature (T-T) | -20 - 60 °C |
| Master (outer) case height | 350 mm |
| Master (outer) case length | 235 mm |
| Harmonized System (HS) code | 84733080 |
| Operating temperature (T-T) | 0 - 50 °C |
| Warranty | 3-Year Warranty |
| Weight | 40 g |
| Dimensions | 34 mm x 65.9 mm x 16 mm |
Product Description
The 2A-130G VGA EDID Emulator is designed for ATEN KVM extender or video extender installations that do not utilize a local monitor at the site where the computer/video source is located. The 2A-130G emulates and stores a default ATEN EDID (Extended Display Identification Information) setting in a non-volatile memory. This means the computer/video source can still "see" the display, even though it is not directly connected. The 2A-130G is suitable for any ATEN KVM or video extender installation where a monitor is not required at the local site, providing a simple, cost-saving, and convenient solution for display-related boot-up problems.
Key Features
ATEN VGA EDID Emulator. Cable length: 0.35 m, Connector 1: USB Type-A, Connector 2: VGA (D-Sub). Weight: 40 g, Width: 34 mm, Depth: 65.9 mm. Package width: 205 mm, Package depth: 245 mm, Package height: 20 mm. Master (outer) case net weight: 1.6 kg, Master (outer) case width: 212 mm, Master (outer) case length: 235 mm
