Brand: Schneider Electric · SKU: 24R2585 · MPN: 24R2585 · Category: Components
Standard 200 Series Power Supply - FPS400-24 - Schneider Electric. The advanced design for AC inputs provides an active sinusoidal current profile for near-unity controlled power factor. The power supply operates as a constant voltage source with maximum load ratings as listed in the specifications. If load current attempts to exceed greater than 110% of maximum current at the rated 25°C load, the output voltage begins to decrease toward zero, thereby limiting the current delivered to the load. Upon removal of overload, normal operation resumes. Automatic shutdown occurs if operating conditions cause excessive output voltage. After the occurrence of an overvoltage shutdown, input power must be interrupted to re-establish the output. After the cause of the shutdown has been removed, the shutdown circuit resets in less than 30 seconds after the removal of input power. The power supplies are UL and UL-C listed (to UL 1950) as having a Safety Extra Low Voltage (SELV) and can be used in Div
| Altitude | –300 to +12,000 m (–1,000 to +40,000 ft) |
|---|---|
| Overshoot | No overshoot at turn on, turn off, power failure |
| Output Voltage | 24.0 V dc, ±0.2 V dc nominal factory setting |
| Relative Humidity | 5 to 95% (noncondensing) |
| Isolation Voltages | 3000 V ac input to output |
| Operating Temperature | -55 to +85°C (–65 to +185°F) |
| Overvoltage Protection | Factory set at 28.0 V dc for DIN rail |
| Load Transient Response | 50 to 100% LOAD CHANGE |
| Over Current Protection | Current limiting to 110% of maximum at the rated |
| Temperature Coefficient | 0.025% per °C |
| Voltage Line Regulation | 2.0% of Vout |
| Voltage Load Regulation | 2.0% of Vout |
| Startup Time (Soft-Start) | 3 s typical at 110 V ac input or 24 V dc, 5 s |
| Ripple and Noise at 20 MHz | 100 mV (peak-to-peak), 10 mV (RMS maximum) |
| Fusing (Non-User Accessible) | 10 A slow-blow 250 V ac/V dc internal fuse |
| Warranty | Not Available |
| Weight | Not Available |
| Dimensions | Not Available |
The Schneider Electric FPS400-24 is a standard 200 Series Power Supply designed for robust operation in industrial environments. It features an advanced AC input design for controlled power factor and operates as a constant voltage source with built-in overcurrent and overvoltage protection. The unit is SELV-rated and suitable for Division 2 and Zone 2 applications. Its sealed, gasketed housing eliminates the need for fans, making it low-maintenance and resistant to corrosive atmospheres. It can also serve as a field power supply for external devices.
