2.45GHz Mini (EIA 0504) Passive Band Pass Filter, P/N 2450BP08A0100
Brand: Johanson Technology, Inc. · SKU: 08A0100 · MPN: 2450BP08A0100 · Category: Components
This is a detail specification for the Johanson Technology P/N 2450BP08A0100, a 2.45GHz Mini (EIA 0504) Passive Band Pass Filter with LGA pads, SMD packaging. Key specifications include an Insertion Loss of 1.0 max @ 25°C and 1.2 max @ 105°C for the 2400 - 2500 MHz frequency range. The Return Loss is specified as 2 max (CW). The device has a Power Capacity of 0.05W. Terminal configuration includes IN/OUT on pins 1 and 4, and GND on pins 2, 3, 5, and 6. It is designed for 50ohm impedance matching. Mechanical dimensions are provided in the datasheet, with a package size equivalent to EIA 0504. The part number explanation shows '2450BP08A0100' as the base part number.
Specifications
| Package Type | SMD, LGA pads |
|---|---|
| Return Loss (dB) | 2 max (CW) |
| Power Capacity (W) | 0.05 |
| Frequency Range (MHz) | 2400 - 2500 |
| Insertion Loss (dB) @ 25°C | 1.0 max |
| Insertion Loss (dB) @ 105°C | 1.2 max |
| Warranty | 18 months in vacuum sealed bag and 1 week after opened (Recommended Storage Conditions). |
| Weight | Unknown |
| Dimensions | EIA 0504 (Mechanical dimensions are detailed in the datasheet) |
Key Features
The 2450BP08A0100 is a miniature, surface-mount passive band-pass filter optimized for the 2.45 GHz ISM band. It is suitable for applications requiring low insertion loss and good return loss at this frequency.
